Tern NBD S5i Electric Bike 500Wh Gloss Blue

Name: Tern Tern NBD S5i Electric Bike 500Wh Gloss Blue
Brand: Tern
Price: 3900.00 GBP
Availability: InStock

£3,900.00 Pre-order Available! Check out now or WhatsApp us for custom configuration (THIS ITEM IS NOT IN STOCK, THIS PURCHASE IS FOR PREORDERS ONLY! ETA FOR THIS ITEM CAN BE CONFIMRED WITH THE STORE!)

AVAILABLE TO RIDE IN 3 DAYS!! Tern NBD S5i electric bike: low-step, easy-handling Bosch-powered commuter with Gates belt drive, Nexus 5-speed hub, and smooth, confident urban performance. Read more

Specifications

Brand:

Tern

Availability:

Pre-order Available! Check out now or WhatsApp us for custom configuration (THIS ITEM IS NOT IN STOCK, THIS PURCHASE IS FOR PREORDERS ONLY! ETA FOR THIS ITEM CAN BE CONFIMRED WITH THE STORE!)

Information

What Makes it a S5i?

Bosch Performance Line motor provides up to 65 Nm of torque and 300% support
Bosch PowerPack 500 powers longer trips, commutes, and journeys
Gates belt drive for clean, quiet, maintenance-free operation
Shimano Nexus INTER-5E internal hub
Magura MT4 hydraulic disc brakes for superior stopping power—even when carrying a passenger and riding fast

NBD Highlights

Ultra-low 39 cm (15.4”) standover height means gentle, low steps are all that’s required to get on and go
Ultra-low center of gravity improves balancing and maneuvering when riding with kids through parks and narrow streets
Fits riders 147 - 190 cm (4'10" - 6'3")
Gaia Rack is certified to carry up to 27 kg (60 lbs) and works with many child seats
Proven safe and reliable: frame and fork have undergone the EFBE Tri-Test to the 140 kg (309 lbs) Maximum Gross Vehicle Weight

SPECIFICATIONS

General Info

Speeds: 1 × 5
Weight: 23.4 kg (51.6 lb)
Gear Range: 34"–90" (2.75–7.22 m)
Folding Size: 38 × 156 × 79 cm (15 × 61.4 × 31.1 in)
Folding Time: 5 sec
Frame Size: One size
Seatpost to Handlebar: 45–52 cm (17.7–20.5 in)
Saddle to Pedal: 70–100 cm (27.6–39.4 in)
Suggested Rider Height: 147–190 cm (4’10”–6’2”)
Max Gross Vehicle Weight: 140 kg (308.6 lb)
Max Rider Weight: 120 kg (264.6 lb)

Frame

Frame: Tern NBD, 6061-AL, patented design, EFBE Tri-Test approved (140 kg)
Fork: Tern Tarsus, 6061-AL hydroformed, EFBE approved (140 kg)

Cockpit

Handlepost: Tern Physis 3D, forged, 5 patented technologies, 12°, 350 mm
Stem: Tern Andros, adjustable, forged, patented design
Headset: Tern Flux by FSA, cartridge bearings
Handlebar: Tern Sweep, 6061-AL
Grips: Ergon
Saddle: Tern Upright by Velo
Seatpost: Tern RideEasy Suspension, 34.9 mm, air cartridge, preload adjustable
Seatpost Clamp: Tern Collar

Brakes

Front Brake: Magura MT4 hydraulic disc
Rear Brake: Magura MT4 hydraulic disc
Brake Levers: Magura
Brake Housing: Magura hydraulic

Wheels

Front Hub: Shimano disc
Rear Hub: Shimano Nexus INTER-5E
Spokes: Stainless steel
Rims: Kinetix Comp (disc)
Tyres: Schwalbe Big Apple, Performance Line, 55-406, puncture protection, reflex sidewall
